Aprilia SL 750 Shiver za 2010-tu

[wulfy]

Ovaj popularni naked je redizajniran za 2010-tu godinu. Još uvjek nemam podatke da li su mjenjane tehničke karakteristike. Dok ne dođem do tog podatka evo prve fotografije novog Shivera

[Highway_Curves]

http://www.ultimatemotorcycling.com/201 ... 50-preview" onclick="window.open(this.href);return false;

"more racing spirit, more aggressive, more ergonomic."

Sjedište se malo spustilo, više sportska pozicija sjedenja. Smanjen profil zadnje gume na 180. Smanjen osovinski razmak, dodati "talasasti" diskovi,
a vješanje i motor ostaju isti.




SPECIFIKACIJE:

2010 Aprilia Shiver 750 | Motorcycle Specifications

Engine type

Aprilia V90 four-stroke longitudinal 90° V-twin engine, liquid cooled, double
overhead camshaft with mixed gear/chain timing system, four valves per
cylinder.

Bore and stroke

92 x 56.4 mm

Total engine capacity

750cc

Compression ratio

11:1

Max power at crankshaft

95hp at 9,000 rpm

Fuelsystem

Ride by Wire integrated engine control system.

Ignition

Digital electronic ignition integrated with injection system.

Start up

Electric

Exhaust
system

2-into-1 exhaust system in 100% stainless steel with three-way catalytic converter and lambda probe

Lubrication

Wet sump

Gearbox

6 speeds

Clutch


Multiplate wet clutch, hydraulically operated

Primary drive


Straight cut gears, drive ratio: 60/31 (1.75)

Secondary drive


Chain.

Drive ratio: 16/44

Chassis

Modular tubular steel frame fastened to aluminium side plates by high strength bolts.
Removable rear subframe.

Front suspension

Upside
down fork with 43mm stanchions. Wheel travel: 4.7 inches.

Rear suspension


Aluminium alloy swingarm with swingarm brace.

Hydraulicshock absorber with adjustable rebound and preload. Wheel travel: 5.1 inches

Brakes

Front:
Dual 320 mm Wave stainless steel floating discs. Radial calipers with four
pistons. Steel-braided brake line. Optional 2-channel Continental ABS system


Rear:
Wave stainless steel 240mm
disc. Twin piston caliper, with steel braided brake line.


rims: Aluminum alloy

Front: 3.50 X 17"
Rear: 5.5 x 17"


Radial tubeless tires;

Front: 120/70 ZR 17

Rear: 180/55 ZR 17

Dimensions

Max. length: 89.1 inches

Max. width: 39.9 inches (at handlebar)

Max. height: 44.7 inches (at instrument panel)

Seat height: 31.5 inches

Wheelbase: 56.7 inches

Trail: 4.3 inches

Steering angle: 25.7 degrees

Tank: 4 gallons
